The system is a fully automatic MAG tube sheet welding system specially designed for the welding of construction machinery shaft sleeves, boiler tube sheets and boiler tie rods. It adopts taper positioner, three-dimensional gantry or intelligent balance device, with a large positioning range and realizes MAG welding without wire feeding. Winding, smooth wire feeding, short wire feeding distance, fillet weld in the form of tube sheet; easy and fast operation. Mainly used in air conditioners, boilers, construction machinery and other industries.
Suitable for construction machinery bushing welding, boiler tube sheet and boiler tie rod MAG welding;
Adopt taper locator, large locating range;
Realize wire feeding, water, electricity and gas without entanglement, easy and fast operation;
Automatic swing during welding;
Assembled on the operation frame for welding, the operation frame adopts pneumatic locking device up and down, left and right, front and rear;
Using 15-20KG wire feeding reel, φ1.0mm and φ1.2mm welding wire can be used;
Weldable material | Carbon steel |
Weldable pipe diameter（mm） | Φ38～Φ260 |
Spinning speed（rpm） | 0.23～4.6 |
Torch inclination | 0º～60ºadjustable |
Protective gas | Argon shielding gas |
Cooling method | Water cooling |
Cooling flow（ml/min） | ≥600 |
Rated current | 320A duty cycle 60% |
Yaw width（mm） | 40 |
Manual height adjustment up and down（mm） | 40 |
Wire diameter（mm） | Φ1.0、Φ1.2（Standard） |
Weight（kg） | 15 |
Dimensions(mm) | 700×250×240 |
