Cold processing will not affect the perpendicularity of the cutting end face of the pipe material products,without burr;Environmental protection,long service life and firm V-shaped clamping design,the workpiece is not loose and not easy to deform,and the weight of the equipment is appropriate,avoiding strong vibration in the cutting process;The drive motor is equipped with torque adaptive program,which makes the cutting process more smooth without winding
Material | Non-alloy steel, low-alloy steel, high-alloy steel, stainless steel, non-ferrous metal, aluminum alloy composite materials and plastic products |
Drive motor | Single-phase AC motor |
Dimension | 390*290*560mm |
15.35*11.42*22.05inch | |
Power | 1300w |
Speed | 30-200r/min |
Pipe inner diameter range | Thickness | Voltage/Power | Weight |
6-76mm | less than 3.5mm | ||
19-120mm | 1-7mm | 110/220/1800W | 75KG |
63.5-182mm | 2-10mm | 110/220/1800W | 90KG |
150-230mm | 2-10mm | 110/220/1800W | 110KG |
215-325mm | 2-10mm | 110/220/1800W | 130KG |
