The application of information

Welding system Precision TIG, plasma or P+T longitudinal ring seam welding system

Welding method TIG/PAW/P+T

Workpiece material stainless steel

Workpiece diameter ≤￠3200mm

Workpiece length ≤6500mm

Weld seam form longitudinal seam, butt ring seam, joint ring seam

System Features:

1) The system is specially designed for the stainless steel industry automation welding system, high-energy beam plasma welding process method, has a good hole penetration ability, in order to ensure single-side welding double-side forming at the same time, as far as possible to improve the welding speed, so as to improve the welding efficiency;

2) The use of plasma +TIG composite welding, plasma substrate, TIG cover, can more effectively improve the quality and efficiency of the weld, TIG welding free arc has good coverage ability, and then with the right amount of filling metal, to achieve the front molding beautiful effect, is a single gun welding efficiency of 1.3-1.5 times;

3) Mainly for the welding of thin-walled containers, stainless steel thickness below 8mm without opening groove, can realize single-side welding double-side molding, more than 8mm opening groove left blunt edge;

4) Strong penetration ability, no bevel for plate thickness below 8mm, greatly reducing the preparation time before welding;

5) Arc energy concentration, welding heat affected zone is small, welding deformation is small;

6) Fast welding speed, plasma than manual argon arc welding reduced 4-5 times of time;

7) Stable industrial control platform is adopted to ensure long-term stable operation of the welding system;

8) Modular design with building blocks to reduce system design and production cycle, which is conducive to large-scale production or maintenance;

9) Huaheng has more than ten years of experience in plasma application, professional training materials, and perfect process guidance and service capabilities;

10) The system is a turnkey project.
